Turbidity Probe
The turbidity probe is based on the nephelometric method (ISO 7027 - EN 27027). A light beam is sent to the sample through an optical lens. The light scattered at 90° by the particles in suspension is collected by the probe through a second lens and it is converted into an electrical signal proportional to the turbidity of the sample. The probe uses infrared light and the measurement is not affected by the colour of the sample. They are suitable for turbidity measurement in water quality monitoring and industrial water treatment and aquaculture.
EXT-TURBNEPH-L
Nephelometric turbidity probe low range
0 - 40 NTU
10 meters of cable length
EXT-TURBNEPH-H
Nephelometric turbidity probe high range
0 - 400 NTU
10 meters of cable length
| Measurement Range | 0 - 40 NTU, 0 - 400 NTU |
|---|---|
| Measurement Technique | Nephelometric |
| Detector | 90° scattered light detector |
| Light Source | Infrared |
| Sample Temperature Range | 0°C to 50 °C |
| Working Pressure | 6 bar maximum at 25 °C |
| Body Material | PVC |
| Connection | Screw terminal |
| Mounting | In-line or In-flow |
| Cable length | 10 meters |
| Sensor Protection | IP68 |
